When using an extension cord, be
sure to use one heavy enough to carry
the current your product will draw. An
undersized cord will cause a drop in line
voltage resulting in loss of power and
overheating. The following table shows
the correct size to use depending on
cord length and nameplate ampere
rating. If in doubt, use the next heavier
gauge. The smaller the gauge number,
the heavier the cord.
fUNCTIONAL DESCRIPTION
1. Inflator attachment
2. Air hose
3. Universal valve adaptor
4. Pressure gauge
5. Accessory storage compartment
Not shown:
Needle nozzle
Beach ball nozzle
OPERATING INSTRUCTIONS
wARNING
:
Risk of Bursting. Too much air pressure causes a hazardous risk of bursting.
Check the manufacturer's maximum pressure rating for objects being inflated.
CAUTION
:
The air hose does not detach from the inflator attachment. Do not attempt to
service or modify the air hose.
wARNING
:
Shock hazard. Under no circumstances should this product be used near water.
wARNING
:
Risk of lacerations or burns. Do not touch work piece or accessory
immediately after operating the tool. They can become very hot. Handle carefully. Always allow
accessories and work piece to cool before handling.
wARNING
:
To reduce the risk of injury, turn off and remove battery from tool or disconnect
plug from power source before making any adjustments or removing or installing attachments or
accessories. Remove any accessory from the attachment before removing or installing the attachment.
NOTE: Refer to Power Unit instruction manual before operating this tool for all safety warnings
and details on installing and removing attachments.
INfLATING
• To switch the tool on, press the variable speed switch on the power unit. The tool speed
depends on how far you press the switch.
• To switch the tool off, release the variable speed switch.
NOTE: This attachment only operates in the forward direction, the forward/reverse slider of the
Power Unit should not be able to be switch to reverse.
Volts
120V
240V
(0-15,2m) (15,2-30,4m) (30,4-60,9m) (60,9-91,4m)
Ampere Rating
More Not more
Than Than
0 -
6 -
10 -
12 -
SAVE ThESE INSTRUCTIONS
Minimum Gauge for Cord Sets
Total Length of Cord in feet
0-25
26-50
(0-7,6m) (7,6-15,2m) (15,2-30,4m) (30,4-45,7m)
0-50
51-100
American Wire Gauge
6
18
16
10
18
16
12
16
16
16
14
12
4
3
3
51-100
101-150
101-200
201-300
16
14
14
12
14
12
Not Recommended
2
5
1
