Cyclic output process data
Byte 0 (motor control)
Bit Description
Bit 0 start CW rotation
Bit 1 start ACW rotation
Bit 2 manual reset
Bit 3 automatic reset
Bit 4 not used
Bit 5 start ACW rotation
Bit 6 stop
Bit 7 start CW rotation
Byte 1 (nominal current 2 setting)
The nominal current setting "nominal current 2" must be below the value of the acyclic,
parameterised "nominal current 1" (see also "Acyclic data").
The "nominal current 2" does not have to be confirmed using the device Set/Reset button.
Bit Description
Bit 0 nominal current setting
...
Bit 3
Bit 4 not used
Bit 5 not used
Bit 6 not used
Bit 7 enable nominal current
setting
Acyclic data
There are three acyclic input bytes and two acyclic output bytes.
Acyclic input process data
Index Type
16 String
17 String
18 String
19 String
20 String
21 String
22 String
23 String
24 String
Byte 0, bit 0 ... 7
68
Byte 1, bit 0 ... 7
Byte 2, bit 0 ... 7
Revision 1, dated 01/2021
Value
0: no control of device for CW rotation
1: control of device for CW rotation
0: no control of device for ACW rotation
1: control of device for ACW rotation
0: no reset
1: reset of overload by rising edge of this command
0: no reset
1: reset of overload by continuous signal of this command
not used
rising edge starts ACW rotation
rising edge stops motor
rising edge starts CW rotation
Value
0000: lowest value for overload trip
...
1111: highest value for overload trip
not used
not used
not used
1. adopt new values
Description Value
VendorName Wöhner GmbH & Co. KG
VendorText woehner.de
ProductName MOTUS
ProductID 36130 / 36131
ProductText IO-Link / Hybrid Motor Starter
SerialNumber stored during production process
HardwareRevision stored during production process
FirmwareRevision stored during production process
ApplicationSpecificTag Stored during production process
Motor current L1 [%]) 255 % (maximum) 2.5-fold
in relation to the currently valid nominal
current
Motor current L2 [%]) 255 % (maximum) 2.5-fold
in relation to the currently valid nominal
current
Motor current L3 [%]) 255 % (maximum) 2.5-fold
in relation to the currently valid nominal
current
®
IO-Link 3 A / 9 A
English.
