InSpectra StO
™
• T here are no predefined alarm limits for
InSpectra StO System Measurement.
2
• T he upper and lower thresholds are set by the user.
• A n intermittent alarm sounds when InSpectra StO
Measurements extend beyond the user-determined
upper or lower threshold.

NotE: Alarm limits are adjustable for monitoring
InSpectra StO Measurements for a particular
2
patient. When the monitor powers off for any
reason, the alarm limits reset to 0 (zero) and 99
percent, which are equivalent to disabling alarm
conditions. If the monitor is not turned off between
patients, the operator should check that the current
alarm values are appropriate.
InSpectra Sto alarm Set-up
2
Press Alarm at the Main Menu to set upper or lower
alarm limit thresholds.
• A djust the upper and lower alarm limits in
increments of 1 or 5.
Upper and lower alarm limits are shown with a red
1
marker and the value in red on the vertical axis of
the display graph.
Decrease in increments of 5 or 1 by pressing the
2
(- 5) or (- 1) button on the menu.
Increase in increments of 1 or 5 by pressing the (+ 1) or (+5) button on the menu.
3
Press Home to confirm selection and return to the Main Menu.
4
alarm Mute Button
The speaker for the alarm is located on the left side of the
1
monitor below the fan outlet grill.
Press the mute button
3
front of the monitor to silence the alarm.
• T he alarm will remain silent for two (2) minutes and will then
reactivate and sound again if the alarm condition continues
to exist.
• T he alarm signal state will inactivate automatically when the
alarm condition ceases to exist.
Alarm Menu
2
2
2
located in the upper left corner on the
1
2 3
1
3
2
2
1
4
figure 15.1
4
figure 15.2
3
figure 15.3
15
