Charging the Battery

1. Plug the monitor into an AC outlet receptacle.
2. Under normal use conditions, it may take approximately five (5) hours
to fully charge the battery.
• T he yellow and green
1
symbols on the right hand side of the monitor indicate when
the battery is charging and/or fully charged (shown only when
operating on AC power).
• T he green indicator light above the Battery Fully Charged
2
symbol is the most reliable indicator that the battery is fully charged.
• T he battery indicator bars
when operating on battery power) approximate the amount of charge remaining.
• P lug the device into AC power when the battery indicator shows one red bar remaining

Replacing the Battery

The lithium ion battery should be replaced every two (2) years or when a fully charged battery will not operate the
device for at least two (2) hours. the battery must be replaced by a Hutchison technology qualified service
technician. Contact the Service Center to return the device for this service.

Software Updates

Hutchinson Technology Incorporated may provide software updates in order to increase the usability of the
InSpectra
™ StO Tissue Oxygenation Monitor.
2

Disposal of Components

InSpectra Sto tissue oxygenation Monitor
™
2

NotE: The InSpectra StO
must be disposed of in accordance with local regulations:
• Mercury in display backlight.
• Lithium ion battery packs.
• Lithium energy cell battery for real time clock.
InSpectra Sto Sensor
™
2
Single Patient Use Only. Dispose of sensor according to local hospital codes and regulations.
u.S. and canada Service center
Telephone: 800.419.1007 or 320.587.1926
Fax: 320.587.1555
Email: biom.usa@hti.htch.com
lights between the battery charge
2
on the LCD screen (shown only
3
Tissue Oxygenation Monitor contains the following electronic components that
2
European Service center
Telephone: +31 26 365 33 70
Fax: +31 26 365 33 72
Email: biom.eu@hti.htch.com
3
1
2
figure 29.1
.
3
29
Maintenance
