Product overview

7
1. Oil drain plug
2. Throttle control
3. Ignition lock
4. Cutting height lever
5. Lift lever for the cutting deck
6. Rearward pedal
7. Forward pedal
8. Parking brake pedal
9. Lock button for parking brake
10. Seat adjustment
826 - 001 -
6
8 9 10
5 4 3 2
11 12 13
11. Type plate
12. Lever to engage or disengage the drive system on
the front axle, FR 2216 MA 4X4
13. Fuel tank cap
14. Cover lock
15. Battery
16. Lever to engage or disengage the drive system,
FR 2213 MA, FR 2216 MA. Lever to engage or
disengage the drive system on the rear axle,
FR 2216 MA 4X4
1
14 15 16
3
