Technical Information

EXOGEN Operating Specifications
Ultrasound frequency
Modulating signal burst width
Repetition Rate
Duty Factor
Effective radiating area (ERA)
Temporal average power
Spatial avg.-temporal avg. (SATA)
Beam non-uniformity ratio (BNR)
Battery
Battery Type
Input Voltage (USB)
Beam type
The essential performance of EXOGEN includes the following:
• Free from the display of incorrect numerical values (numbers) associated
with the ultrasound therapy
• Free from the production of unwanted ultrasound output
• Free from the production of excessive ultrasound output
• Free from the production of unintended or excessive transducer surface temperature
27
1.5 +/- 5% MHz
200+/- 10% microsecond (µs)
1.0+/- 10% kilohertz(kHz)
20%
3.88 +/- 10% square cm (cm )
2
117 +/- 30% milliwatts(mW)
30+/- 30% mW/cm
2
4.0 maximum
3.7 VDC, 700 mAh

Lithium-ion

5.0 VDC, 2.6A max.
Collimated
