INOXPAN S.L.
3.3. INSTRUCTIONS FOR FITTING UNDER A WORKTOP
Only for models:
Make sure that the installation does not obstruct the front ventilation grille. This unit is designed to
fit under worktops of 820-890 mm height, using the adjustable ventilation grille to guarantee that
the feet are hidden from view at the front. Remove the screws from the adjustable ventilation grille
and slide it to the required height. Tighten the screws to secure the grille in its position.
If the unit is completely built-in, when fitting the kitchen skirting board, make sure that the
ventilation grilles in this skirting board can dissipate at least 300 square centimetres, so the hot air
can be dispersed without any obstruction. Otherwise, the unit will have to work more, increasing
electricity consumption.
Also make sure that the door can open and close freely in the chosen location.
NOTE: When pushing the unit into its space, make sure that the power cable is not trapped.
•
PVMB15-7
•
PVMB 30-16
•
PVMB 60-53
•
PBE 182-190CRR
•
PBE 89-66CRR
9
WINE CABINETS
