AUDIO SETTINGS
[PRO EQ] Adjusts your own sound settings.
• The settings are stored to [USER] in [PRESET EQ].
• The settings made may affect the current settings of [EASY EQ].
[62.5HZ]
[LEVEL –09] to [LEVEL +09] ([LEVEL 00]): Adjusts the level to memorize for each source.
(Before making an adjustment, select the source you want to adjust.)
[ON]: Turns on the extended bass. ; [OFF]: Cancels.
[100HZ]/[160HZ]/[250HZ]/[400HZ]/[630HZ]/[1KHZ]/[1.6KHZ]/[2.5KHZ]/[4KHZ]/
[6.3KHZ]/[10KHZ]/[16KHZ]
[LEVEL –09] to [LEVEL +09] ([LEVEL 00]): Adjusts the level to memorize for each source.
(Before making an adjustment, select the source you want to adjust.)
[Q FACTOR] [1.35]/[1.50]/[2.00]: Adjusts the quality factor.
[AUDIO CONTROL]
[BASS BOOST] [LEVEL +01] to [LEVEL +05]: Selects your preferred bass boost level. ;
[OFF]: Cancels.
[LOUDNESS] [LEVEL 01]/[LEVEL 02]: Boosts low or high frequencies to produce a well-
balanced sound at low volume. ; [OFF]: Cancels.
[SUB.W LEVEL]*1 [SPK-OUT]*2
[PRE-OUT]
[SUBWOOFER [ON]: Turns on the subwoofer output. ; [OFF]: Cancels.
SET]
(Not applicable when 3-way crossover is selected.)
[SUB.W 00] to [SUB.W +06] ([SUB.W +03]): Adjusts
the output level of the subwoofer connected via speaker
lead. (Page 34)
[SUB.W –50] to [SUB.W +10] ([SUB.W 00]): Adjusts
the output level of the subwoofer connected to the
lineout terminals (SW) through an external amplifier.
(Page 35)
[FADER] (Not applicable when 3-way crossover is selected.)
[POSITION R15] to [POSITION F15] ([POSITION 00]): Adjusts the front
and rear speaker output balance.
[BALANCE]*3 [POSITION L15] to [POSITION R15] ([POSITION 00]): Adjusts the left and
right speaker output balance.
[VOLUME ADJUST] [LEVEL –15] to [LEVEL +06] ([LEVEL 00]): Presets the initial volume level
of each source by comparing to the FM volume level. (Before adjustment,
select the source you want to adjust.)
[AMP GAIN] [LOW POWER]: Limits the maximum volume level to 25. (Select if the
maximum power of each speaker is less than 50 W to prevent damaging
the speakers.) ; [HIGH POWER]: The maximum volume level is 35.
[SPK/PRE OUT] (Not applicable when 3-way crossover is selected.)
Depending on the speaker connection method, select the appropriate
setting for the desired output. (See "Speaker output settings" on
page 22.)
[SPEAKER SIZE] Depending on the crossover type you have selected (see [X ' OVER TYPE]),
2-way crossover or 3-way crossover setting items will be shown. (See
"Crossover settings" on page 23.)
[X ' OVER]
By default, 2-way crossover type is selected.
[DTA SETTINGS]
For settings, see "Digital Time Alignment settings" on page 25.
[CAR SETTINGS]
[X ' OVER TYPE] Caution: Adjusts the volume before changing the [X ' OVER TYPE] to avoid
the sudden increase or decrease of the output level.
[2-WAY] (Displayed only when [3-WAY] is selected.)
[YES]: Selects two way crossover type. ; [NO]: Cancels.
[3-WAY] (Displayed only when [2-WAY] is selected.)
[YES]: Selects three way crossover type. ; [NO]: Cancels.
*1, *2, *3: (page 22)
