INSTALL BATTERY

1. Insert your finger tip into the slot (1), then push down on
top of the battery cover and slide it off to remove (2).
2. Slide the battery into the slot (3) by aligning the contacts
and press down (4) until you hear the "click".
Correct
3. Align the cover tabs with the slots on the back of the device
(1) and slide the battery cover onto the unit until it snaps
into place (2).
If the battery is not correctly placed in the compartment, the handset will not turn on
and/or the battery may detach during use.
Correct
16
Incorrect
Incorrect

REMOVE BATTERY

1. To remove the battery cover, insert your finger tip into the
slot (1), then push down on top of the battery cover and
slide it off (2).
2. Insert your fingernail into the slot and lift the battery (3),
and pull the battery (4).
3. Align the cover tabs with the slots on the back of the
device and slide the battery cover onto the unit until it
snaps into place.

CHARGING YOUR BATTERY

1. Connect the USB data cable into the cableless wall
adapter.
2. Plug the USB data cable into the phone' s Charging/Data
Port (making sure to align the connector as it appears in
the image to the right) and the wall adapter end into an
electrical outlet.
• If the battery connector is not properly aligned, damage could occur to the charging
connector and the phone may not charge.
• The main plug is used as the disconnect device and remains readily operable.
