Trouble-shooting

Symptom
The product will not
work, even though
the controls is used
correctly.
The product runs up
and down unevenly.
Contact Pressalit Care or your dealer if the problem cannot be remedied.
Do not attempt to repair the product yourself, as this will invalidate the
guarantee.

Technical data

Max load
Materials
Weight
en
IP class
Max consumption
Voltage
Frequency
Current
16
Cause
Fault in power supply.
The sliding brackets
are not properly
lubricated.
100 kg / 220 lbs
Aluminium
Plastics
R4750: 16,36 kg / 36,06 lbs
R4751: 15,94 kg / 35,14 lbs
R4752: 16,08 kg / 35,45 lbs
R4780: 18,12 kg / 39,94 lbs
R4781: 17,70 kg / 39,02 lbs
R4782: 17,84 kg / 39,33 lbs
IPX6

Power specifications

75 W
Mains connection: 230V/120V/100V
50/60 Hz
1.6 A
Action
Check that all wires and
plugs are intact and
correctly connected.
Contact Pressalit A/S or
your local dealer.
Oil the sliding brackets
as described under
"Maintenance".
