Dimensiones De El Gabinete - Altronix ACMCBJ Serie Guia De Instalacion

1.25"
(31.75mm)
1.5"
(38.1mm)
8.5"
(215.9mm)
18.0"
(457.2mm)
Altronix no es responsable de ningún error tipográfico.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIACMCBJ Series
- 12 -

Dimensiones de el gabinete

18" x 14.5" x 4.625" (457.2mm x 368.3mm x 117.5mm)
1.5"
(38.1mm)
4.5"
(114.3mm)
1.0"
(25.4mm)
1.0"
(25.4mm)
1.0"
(25.4mm)
1.0"
(25.4mm)
2.75"
(69.85mm)
14.5"
(368.3mm)
2.5"
(63.5mm)
14.5"
(368.3mm)
4.5" 4.5"
(114.3mm) (114.3mm)
14.5"
(368.3mm)
E28S
2.5" 1.5"
(63.5mm) (38.1mm)
1.5"
(38.1mm)
1.0"
(25.4mm)
18.0"
(457.2mm)
1.0"
(25.4mm)
1.5"
(38.1mm)
2.75"
(69.85mm)
1.25"
(31.75mm)
1.5"
(38.1mm)
2.5"
(63.5mm)
6.0"
(152.4mm)
18.0"
(457.2mm)
MEMBER
ACMCBJ Series
