10-Channel Personality; 9-Channel Personality - Chauvet Professional NEXT NXT-1 Manual De Usuario

10-Channel Personality

10CH

9-Channel Personality

9CH
In the 9- and 81-channel DMX personalities of Next™ NXT-1, only red, green, and
blue values can be changed. These DMX personalities use the unique Auto
Color function. Auto Color automatically mixes and blends the white emitted by
the LEDs into the RGB values from the controller to expand the range of color
and enhance color rendering.
Next™ NXT-1 User Manual Rev. 1
Channel Function
1 Pan
2 Pan Fine
3 Tilt
4 Tilt Fine
5 Pan/Tilt Speed
6 Control
7 Red
8 Green
9 Blue
10 White
Channel Function
1 Pan
2 Pan Fine
3 Tilt
4 Tilt Fine
5 Pan/Tilt Speed
6 Control
7 Red
8 Green
9 Blue
Configuration And Operation
Value Description
000ó255 0–540°
000ó255 Fine (16-bit) pan control
000ó255 0–270°
000ó255 Fine (16-bit) tilt control
000ó255 Fast to slow
000ó199 No function
200ó209 Resets all (hold 3 seconds)
210ó255 No function
000ó255 0–100%
000ó255 0–100%
000ó255 0–100%
000ó255 0–100%
Value Description
000ó255 0–540°
000ó255 Fine (16-bit) pan control
000ó255 0–270°
000ó255 Fine (16-bit) tilt control
000ó255 Fast to slow
000ó199 No function
200ó209 Resets all (hold 3 seconds)
210ó255 No function
000ó255 0–100%
000ó255 0–100%
000ó255 0–100%
Page 45 of 45
