Altronix ALTV2416UL Serie Guia De Instalacion página 12

1.20"
(31mm)
1.40"
(36mm)
5.10"
(130mm)
(330mm)
5.10"
(130mm)
3.25"
(83mm)
1.0"
(25mm)
Altronix no es responsable de ningún error tipográfico.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIALTV2416UL Series
- 12 -
Dimensiones de el gabinete(H x W x D) para:
• ALTV2416ULX • ALTV2416ULCBX
• ALTV2416300UL • ALTV2416300ULCB
• ALTV2416600UL • ALTV2416600ULCB
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.6mm)
1.40" 4.85"
(36mm) (123mm)
0.75"
(19mm)
13.0"
1.0"
(25mm)
4.85"
(123mm)
12.5"
(318mm)
11.0"
(279mm)
10.5"
(267mm)
D04R
1.40"
(36mm)
1.20"
(31mm)
3.25"
(83mm)
0.75"
(31mm)
(19mm)
0.9375"
(24mm)
0.9375"
(24mm)
3.25"
(83mm)
3.25"
(83mm)
1.0"
(25mm)
1.0"
(25mm)
ALTV2416UL Series
1.20"
1.40"
(36mm)
5.10"
(130mm)
6.5625"
(167mm)
