NO. Parts Name
1A POWER SUPPLY CABLE 14A x 3C x 3M - SJTW
1A POWER SUPPLY CABLE VDE 1.5 x 3C x 3M - H07RNF(IP44)
1B POWER SUPPLY CABLE 14A x 3C x 0.3M - SJTW
1B POWER SUPPLY CABLE VDE 1.5 x 3C x 0.3M - H07RNF(IP44)
1C POWER SUPPLY CABLE 14A x 3C x 2.7M - SJTW
1C POWER SUPPLY CABLE 1.5 x 3C x 2.7M - H07RNF(IP44)
2A PRCD INTERRUPTER PROTECTION (110V)(220V)
2B PRCD INTERRUPTER PROTECTION (110V)(220V)
3A CORD ARMOR Ø10.3
3B CORD ARMOR Ø15.5
4 CABLE CLIP
5 PANHEAD TAPPING SCREW M4 x 14
6 TRIGGER SWITCH (LOCK-OFF)
7 N/A
8 PANHEAD TAPPING SCREW M4 x 16
9 ELECTRONICS UNIT (110V)(220V)
10 PANHEAD TAPPING SCREW M4 x 8
11 BRUSH SPRING 0.4x4x3T
12 CARBON BRUSH HOLDER 7x17
13 INSULATION PLATE 10x38x1
14 CARBON BRUSH 7 x 17 x 17
15 PANHEAD MACHINE SCREW M4 x 6
16 MOTOR HOUSING
17 HANDLE HALF-RIGHT
18 HANDLE HALF-LEFT
19 N/A
20 CARBON CAP
21 PANHEAD TAPPING SCREW M4 x 12
22 PANHEAD TAPPING SCREW M4 x 25
23 PANHEAD TAPPING SCREW M4 x 50
24 GUIDE ROLLER ASSY.
25 STATOR (110V-100x54.1x65) (220V-100x54.1x65)
26 PANHEAD TAPPING SCREW-A-W/WASHER M5 x 80
27 ALL BEARING 6200 LLU
28 FAN SHROUD
29 ARMATURE (110V-100x54.1x65) (220V-100x54.1x65)
30 BALL BEARING 6202-2NSE
31 BEVEL PINION GEAR M2.35 x 6T
32 EXTERNAL STAR WASHER M4
33 WIRE LEAD 20AWG x 35cm
34A/B CRIMP CAP CONNECTOR A/(C4) B/(C5)
35 GEAR HOUSING
36 SPRING WASHER M5
37 PANHEAD TAPPING SCREW M5 x 35
38 SPINDLE LOCK BUTTON
39 SPRING Ø0.9 x Ø7.4 x Ø9.2 x 5T x 16L
40 ARBOR LOCK
41 NEEDLE BEARING TA 1212
42 BEVEL GEAR M2.35 x 37T
43 N/A
44 SPINDLE M10xP1.5-116.6MM
45 PARALLEL KEY 5 x 5 x 10
46 INTERNAL CIRCLIP R-62
47 BALL BEARING 6206-ZZ
48 GEAR PLATE
49 L-CLEVIS PIN
50 E-CLIP E-5
51 SOCKET CAP SCREW M5 x 25
GB
PARTS LIST (C14)
Q'TY NO. Parts Name
1 52 OIL SEAL Ø25 x Ø35 x 5
1 53 FELT OILER Ø25 x Ø35 x 2.5
1 54 RUBBER FENDER Ø75 x Ø91 x 4
1 55 INNER SAFETY COVER
1 56 DUST PORT BRACKET-LEFT
1 57 DUST PORT PLUG
1 58 FLAT WASHER Ø4 x Ø10 x 1
1 59 PANHEAD TAPPING SCREW M4 x 10
1 60 DUST ATTACHMENT
1 61 BLADE GUARD BRUSH
1 62 DUST PORT BRACKET-RIGHT
3 63 TUBE GUIDE-LEFT
1 64 TUBE GUIDE-RIGHT
- 65 TUBE 0.24M (Ø6.4 x Ø8.5)
2 66 FLAT HEAD TAPPING SCREW M4 x 16
1 67 WATER NOZZLE ASSY.-L
4 68 WATER NOZZLE ASSY.-R
2 69 CABLE PROTECTOR 5/16" x 75CM
2 70 WATER FEED CONNECTOR KIT
2 71 WATER COUPLING
2 72 FITTING
2 73 RETAINING PLATE Ø25.1 x Ø90 x 1.5
1 74 FLAT HEAD MACHINE SCREW M5 x 8
1 75 INNER FLANGE (Ø25.4) (Ø22.2)
1 76 COUNTER FLANGE
- 77~79 N/A
2 80 SOCKET CAP SCREW M8 x 16
2 81 FRONT HANDLE
6 82 COMBINATION WRENCH M17
6 83 HOSE JOINER
1 84 ZIP TIE KTV-150BK
1 85 LED INDICATOR LIGHT
2 86 SPLASH GUARD
1 87 WIRE HOSE CLAMP
1 88 CLIP-FEMALE
1
89 PLASTIC RING Ø74 x Ø91.5 x 0.25
1 90 PANHEAD TAPPING SCREW M4 x 20
1 91 SPRING
1 92 TRUSS HEAD MACHINE SCREW
1 93 O-RING Ø35 x 1.5
1 94 BOLT M10 x P1.5
1
8 A DRY DUST SKID ASSY
6 A1 DUST SKID BODY
1 A2 PLUNGER
2 A3 SPRING Ø1.0 x Ø6.2 x Ø8.2 x 35L x 10T
1 A4 CRADLE PLATE
1 A5 FLAT HEAD TAPPING SCREW M4 x 14
1 A6 SOCKET CAP SCREW M6 x 16
- A7 HEX NUT M6 x P1.0
1 A8 BAYONET PIN
2 A9 TORSION SPRING
1 A10 BEARING BOLT Ø8 x 43
1 A11 MOUNTING STRAP
1 A12 PANHEAD TAPPING SCREW M4 x 10
1 A13 TETHER
1 A14 TRUSS HEAD TAPPING SCREW M4 x 8
4 A15 TRUSS HEAD MACHINE SCREW M4 x 8
