Minimum core diameter of connecting cable:
0-8 m
EP13/18 230V 0.75 mm²
EP13/18 120V
0.75 mm²
EP211 230V
2.5 mm²
EP211 120V
5.5 Hydraulic drawings
EP13/18S
EP211S
5.6 Flowcharts
EP13/18:
Bega International BV – Assembly Manual Betex® EP13, EP18 & EP211 series – Oct. 2015
8-15 m 15-30 m 30-46 m
1 mm² 1.5 mm² 2.5 mm²
1.5 mm² 2.5 mm²
4 mm² 6 mm² 10 mm²
EP13/18D
EP211D
15
0-25 ft 25-50 ft
18 AWG 16 AWG
4 mm² 18 AWG 14 AWG
12 AWG 10 AWG
EP18SS
EP211SS
EP211:
50-100 ft 100-150 ft
14 AWG 12 AWG
12 AWG 10 AWG
8 AWG 6 AWG
GB
EP18D
EP211DS
