Gun Drawing
2
1
PARTS LIST
R
ef.
Replacement Part
No.
No.
1
See Chart 1, p.4
2
See Chart 2, p.4
3
FLG-304-K5
4
FLG-305
5
FLG-465
6
FLG4-364-K
7
FLG4-366-K
8
FLG4-468-K
9
P-MB-51
10
FLG4-108-K
11
JGA-4044
FLG-463
JGA-4035-K5
FLG4-488-K t
Additional Spray Gun Accessories on page 9.
www.carlisleft.com
4
3
11
t
t
t
Description
Air Cap & Ring Kit
Fluid Tip & Seal Kit
Fluid Tip Seal (Kit of 5)
Baffle
Spreader Air Adjustment Valve
Needle Knob, Spring, Bushing & Gasket Kit
FLG4 Needle, Needle Packing & Nut Kit
Air Valve & Gasket Kit
Air Inlet Nipple
Trigger, Trigger Stud & Screw
Fluid Inlet & Nut Kit
Air Cap #3 HVLP Test Cap
Needle Packing (Kit of 5)
FLG4 Gun Repair Kit (Contains 1 each: Fluid Tip Seal, Needle Packing,
Trigger Stud, Trigger Screw, and Gasket for Air Valve & Needle Bushing.)
6 / 9
5
t
t
9
7
8
7
6
10
t
Ind. Parts
Required
1
1
1
1
1
1
1
1
1
1
1
SB-2-777-R1 (2/2018)
