Version 1.0
Published November 2018
Copyright©2018 ASRock INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identification or explanation and to the owners' benefit, without intent to
infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or fitness for a particular
purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of profits, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate"
ASRock Website: http://www.asrock.com
Publicidad
Tabla de contenido
Manuales relacionados para ASROCK H310CM-HDVP/DASH
Resumen de contenidos para ASROCK H310CM-HDVP/DASH
- Página 1 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
- Página 2 You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply) The terms HDMI®...
- Página 3 H310CM-HDVP/DASH Motherboard Layout RoHS CPU_FAN1 ATX12V1 USB 2.0 USB 2.0 T: USB0 T: USB2 B: USB1 B: USB3 USB 3.1 Gen1 Top: T: USB0 RJ-45 B: USB1 HD_AUDIO1 CHA_FAN1/WP H310CM-HDVP/DASH PCIE1 CMOS PCIE2 Battery Intel H310 PCIE3 BIOS PCI1 PANEL1...
- Página 4 No. Description ATX 12V Power Connector (ATX12V1) CPU Fan Connector (CPU_FAN1) 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1) ATX Power Connector (ATXPWR1) USB 2.0 Header (USB_8_9) (shared with USB3_2_3) SATA3 Connector (SATA3_3) SATA3 Connector (SATA3_2) SATA3 Connector (SATA3_1) SATA3 Connector (SATA3_0) Clear CMOS Jumper (CLRMOS1) System Panel Header (PANEL1) Chassis Fan Connector (CHA_FAN2)
- Página 5 H310CM-HDVP/DASH I/O Panel No. Description No. Description PS/2 Mouse Port Microphone (Pink)** COM Port USB 3.1 Gen1 Ports (USB01) D-Sub Port USB 2.0 Ports (USB0123) LAN RJ-45 Port* HDMI Port Line In (Light Blue)** DVI-D Port Front Speaker (Lime)** PS/2 Keyboard Port * There are two LEDs on each LAN port.
- Página 6 ** To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi- channel audio feature through the audio driver. Please set Speaker Configuration to “7.1 Speaker”in the Realtek HD Audio Manager. Function of the Audio Ports in 7.1-channel Configuration: Port Function...
-
