Before You Connect to the Network: Mounting Kit Instructions

The switch is supplied with rubber feet for stationing it on a flat surface and
mounting brackets and screws for mounting it in a rack.
Installing the Switch on a Flat Surface
The switch can be installed on any appropriate level surface that can safely
support the weight of the hubs and their attached cables. There must be
adequate space around the switch for ventilation and access to cable
connectors.
To install the switch on a flat surface:
Set the switch on the flat surface and check for proper ventilation.
1
Allow at least 5.1 cm (2 inches) on each side for proper ventilation and
12.7 cm (5 inches) at the back for power cable clearance.
Attach rubber feet on each marked location on the bottom of the
2
chassis.
The rubber feet are optional but are recommended to keep the unit
from slipping.
Installing the Switch in a Rack
The switch can be installed in most standard 48.3-cm (19-inch) racks.
To install the switch in a rack:
Use the supplied screws to attach a mounting bracket to each side of
1
the switch.
Position the switch in the rack and align the holes in the mounting
2
bracket with the holes in the rack.
Insert and tighten two screws appropriate for your rack through each of
3
the mounting brackets.
Unmanaged Switches System Infor m ation Guide
NOTE: For racks that
are not prethreaded, cage
nuts are provided.
