AXIS T91A Series Installation Guide
Install the AXIS T91A63 Ceiling Mount
Hardware overview,
1. Refer to
supplied parts.
2. Route the network cable through or along the ceiling.
3. Attach the bracket holder in the desired position in the ceiling using screws
that are appropriate for the ceiling material and the weight of the camera
and bracket. Maximum weight allowed 15kg (33lbs).
4. Route the necessary cables through the ceiling bracket, securing them in the cable holder.
www.a1securitycameras.com email: sales@a1securitycameras.com
on page 4 and page 5 for information on the
Note: Do not use bracket holder
as a temporary support
with the ceiling bracket.
