Assembly Instructions for Floating Swivel Mount
X
1/2" Bolt
(4 used in this step)
33. Hold and attach the flat side of the Mounting Frame (X) to the Swiveling Bracket (W) using
four 1/2" Bolts (7) and four Washers (13 and 14). Make sure the recess holes on the Mounting
Frame are at the bottom. Tighten all bolts with the provided 4 mm hex wrench
W
U
(4 used in this step)
⑦
Lock Washer
⑬
31
X
W
14
14
13
7
Flat Washer
(4 used in this step)
⑭
13
7
