- Página 2 Keep this Assembly Manual for future reference. Two adults recommended for assembly This product is not intended for commercial use. Do NOT return this product. Follow little seeds on For missing or broken parts - Visit littleseedskids.com - Call 1-800-489-3351...
-
Página 3: Helpful Hints
Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Tube Monday-Friday 9am - 5pm CST Visit littleseedskids.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 1 HOUR - Open your item in the area you plan to keep it for less heavy lifting... -
Página 4: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. - Página 5 Board Identification Headboard Top Rail Bottom Rail 39060103030 39060103010 39060103020 Center Support Footboard Side Panel 35321103050 39060103060 39060103040 littleseedskids.com...
- Página 6 Board Identification Bed Slat (x2) End Support (x2) Bed Board (x2) 35321000070 35321000080 35321000090 SIDE Drawer Front (x2) Drawer Side (x4) 39060103100 39991149346200C BACK Drawer Bottom (x2) Drawer Back (x2) 39991341090510D 39991149089490B littleseedskids.com...
- Página 7 Board Identification SIDE BACK SIDE littleseedskids.com...
-
Página 8: Parts List
Parts List Actual Size (x1) (x8) (x4) (x8) (x11) (x4) #A22610 #A23100 #A21660 #A53510 #A22620 #A23050 4mm hex key wood dowel angle bracket confirmat cam bolt cam lock (x8) (x8) (x36) (x20) #A12930 #A21970 #A12120 #A11080 #8 x 1-1/8" screw drive fastener #8 x 7/16"... - Página 9 Parts List Not Actual Size Left Cabinet Member Right Cabinet Member Left Drawer Member Right Drawer Member (x2) #A56750 Drawer Slide Kit (x2) #A54900 Metal Drawer Brace littleseedskids.com...
- Página 10 Step 1 Note: This unit should be assembled on a clean surface. This bed can be assembled with the drawers on the right side of the bed or the left side. This step shows both options. The Head Board (A) has square corners and Foot Board (F) has curved corners.
- Página 11 Step 2 Left Cabinet Member (x8) (x6) #A12930 #A11080 Right Cabinet Member (x1) #A56750 This step is for the drawers to be on the left side of the bed. Marked with an "R" Marked with an "L" * raw edges are shaded littleseedskids.com...
- Página 12 Step 3 Left Cabinet Member (x8) (x6) #A12930 #A11080 Right Cabinet Member (x1) #A56750 This step is for the drawers to be on the right side of the bed. Marked with an "L" Marked with an "R" * raw edges are shaded littleseedskids.com...
- Página 13 Step 4 Left Cabinet Member Right Cabinet Member (x4) (x3) (x6) (x1) #A22620 #A11080 #A21660 #A56750 Quick Assembly Proper orientation of CAM LOCK Refer to page 3 for cam lock & cam bolt procedure if needed. Align the three holes in center support (E) with three holes in the slides (16a) and (16b).
- Página 14 Step 5 (x8) (x4) (x8) #A12120 #A22610 #A21660 (x8) #A53510 * raw edges are shaded littleseedskids.com...
- Página 15 Step 6 (x1) (x2) #A23100 #A23050 littleseedskids.com...
- Página 16 Step 7 (x1) (x2) #A23100 #A23050 Attach the Top Rail and Bottom Rail to the Center Support first, then attach the ends to the Headboard second. You may need the help of another person for this step. littleseedskids.com...
- Página 17 Step 8 (x1) (x4) #A23100 #A23050 littleseedskids.com...
- Página 18 Step 9 (x8) #A12120 Attach the bed slats to the Top Rail and Side Panel by positioning the angle brackets with the holes and using the screws as shown. littleseedskids.com...
- Página 19 Step 10 (x8) (x4) #A12120 #A54520 Finished Edge Finished Edge SIDE SIDE Fasten the brackets on the same surface as the small metal slide holes. littleseedskids.com...
- Página 20 Step 11 (x8) #A12120 SIDE Be sure the groove in the drawer sides are centered with groove in the drawer front. SIDE littleseedskids.com...
- Página 21 Step 12 SIDE raw surface SIDE littleseedskids.com...
- Página 22 Step 13 (x8) #A21970 You will need to tap the drive fasteners with a hammer to securely fasten. SIDE BACK SIDE littleseedskids.com...
- Página 23 Step 14 (x4) #A12120 (x2) #A54900 BACK SIDE littleseedskids.com...
- Página 24 Step 15 Left Drawer Member (x8) (x4) Right Drawer Member (x2) #A17400 #A11080 #A50435 (x2) #A56750 (x2) Marked with #A50520 an "L" Attach the drawer slides first before laying the drawer down to attach the handle. SIDE BACK SIDE Marked with an "R"...
- Página 25 Step 16 Install the drawers as shown. roller cabinet member Note: The drawer bracket holes are slotted. Drawer fronts can be adjusted by loosening screws, making needed adjustments and retightening screws. drawer runner roller littleseedskids.com...
- Página 26 Step 17 littleseedskids.com...
