Tripp-Lite U457-025-G1-WPG Guia De Inicio Rapido página 3

Installation
Remove the back cover (side with the screw holes) of the SSD/HDD
1
enclosure.
Connect your 2.5 in. SATA SSD/HDD to the SATA connector.
2
Once the SATA SSD/HDD is securely in place, replace the back cover,
3
ensuring the screw holes line up with one another.
Using the included screwdriver, screws and washers, fasten the 10
4
screws and washers securely to the enclosure.
Note: In order to comply with IP66 standards, screws need to be properly
tightened to the enclosure.
Connect the built-in USB 3.1 Type-C cable to an available USB port on
5
your computer.
Specifications
Drive Connection
USB Connection
Maximum Data Transfer Rate 10 Gbps (U457-025-G2-WPB)
SSD/HDD Supported
Operating Temperature
Relative Humidity
Dimensions
22-Pin SATA Data + Power
USB Type-C (Male)
5 Gbps (U457-025-G1-WPG)
2.5 in. SATA I/II/III HDD/SSD
50° to 122°F (10° to 50°C)
10% to 80% RH, Non-Condensing
0.94 x 3.7 x 5.8 in. (24 x 94 x 148 mm)
3
