Breeze Tripod fan Installation Instructions
1. Insert the wooden legs (6) into the holes of the post coupling (3) until you can not push the wooden legs (6) in any
further, and then sercure the wooden legs (6) by tightening the leg screws (5). Do not over tighten, it will damage the
wooden legs (6). Fig. 1
2. Loosen the height adjustment knob (4) and pull out the height adjustment pipe (2) to the desired height. Tighten the
height adjustment knob (4) firmly. Fig. 1
3. Place the fan head assembly (1) onto the top of the height adjustment pipe (2). Secure it by tigntening the fixed knob
(8). Fig. 1
4. Loosen the tilt adjustment knob (7) and adjust the fan head upwards or downwards to your desired tilt angle.
Secure the fan head tilt angle by tightening the tilt adjustment knob (7) firmly. Fig. 1
5. Insert the plug into the mains socket outlet and ensure it is fully plugged in.
FAN SPEED CONTROL (Fig.2)
The fan has 3 different speeds which are controlled by the speed control switch.
III
- High speed
II
- Medium speed
I
- Low speed
0
- OFF
FAN SWING CONTROL (Fig.3)
The oscillation of the fan is controlled by the Oscillation knob.
1. Push down the oscillation knob, the fan will oscillate from left to right.
2. Pull up the oscillation knob, the fan will stop oscillating.
4 | P a g e
INSTALLING THE FAN
USING YOUR FAN
Fig. 2
Fig. 3
