Tool Specifications

Laser distance meter
The symbols on the device have the following meaning:
Laser irradiation
Do not look into the beam
Laser class 2
according to IEC 60825-1: 2007
Max. power output:
Wavelength:
Order number
Measuring range, direct
Measuring range,
with target plate
Inclination measurement
Measuring accuracy, typ.
– Distance measurements
– Inclination measurements
Smallest display unit
Laser point Ø in
10/50/100 m
Automatic shut-off
Laser/device
Memories of measured
values, amount
Automatic release/timer
Batteries: Type AA
Battery operating life
Protection class
Storage temperature
Operating temperature
Weight, approx.
* For the following situations, using a target plate is recom-
mended already for closer working ranges:
- Poorly reflecting surfaces
- Reflecting surfaces (glass, metal, etc.)
- Bright ambient light, such as direct sun light
** Under unfavourable conditions, e.g., for temperature altera-
tions, for a poorly reflecting surface or bright ambient light, the
error of measurement can be up to 3 mm.
For working ranges in excess of 30 m, the accuracy declines by
0.1 mm/m, and by 0.15 mm/m for large distances in mode menu.
The device is intended for measuring distances and
WDM 201
inclinations, as well as for the calculation of areas
and volumes. The measured values determined by
the device may not be used to control or trigger
other equipment, machinery or systems. The device
is not suitable for operation in hazardous areas.
For damage caused by usage other then intended,
the user is responsible.
<1mW
635 nm
1 Main function
0714 640 720
2 Sub-function
0.05 m – 100 m*
3 Electronic spirit level
4 Timer
200 m
5 Displays for intermediate values
6 Main display
± 45°
7 Detail indication
8 Battey status display
± 1.0 mm**
9 Status bar
± 0.3°
10 Zoom level
0.1 mm
11 Camera image
12 Crosshair
13 Inclination angle
6/30/60 mm
14 Measured value of distance
6 min
20
15 Button for inclination, horizontal distance,
5 s – 60 s
2 x 1.5 V
16 Button for menu functions/equal-to-button for
5 000 distance
measurements
17 Minus button for calculations
IP 54 (IEC60529)
18 Trapezium measurement
19 Indirect measurement – Pythagoras function
–25 ... +70 °C
20 Solid angle measurement
–10 ... +50 °C
21 Memory of measured value/parameter
0.2 kg
22 Clear/off
23 Automatic release/timer
24 Change measuring level
25 Surface measurement/volume measurement
26 Add button for calculations
27 Viewfinder, zoom button
28 On/Off switch, distance measurement, tracking
29 Type plate

Use as Intended

Display Symbols

Keypad/Pushbuttons
marking out
calculations

Inserting Batteries

A
Replace the batteries when this symbol
appears in the display.
Use only alkaline batteries.
When not using for longer periods, remove the
batteries to avoid the danger of corrosion.
15
