CLEANING THE FILTERS

Filters
The filter system consists of: 2 multi-cyclone filters to vacuum the smallest particles (in the dust
It is necessary to clean the 3 last filters regularly to avoid operating problems.
Motor filter
To clean the motor filters (filters situated next to the dust collector), switch off the appliance,
take out the dust collector and take out the filter housing that is situated on top of the motor.
Take the bracket with the filters out of the filter housing and remove the grey filter to wash it in
soapsuds (approximately every 3 months). Then wash the bracket with the white motor filter in
soapsuds. When the filters are completely dry, put them back in the appliance. To do so, put
the grey filter back in the bracket with the white filter. Then put the bracket with the motor
filters back in the filter housing and put it back into the appliance in a correct way.
Air filter
This air filter (situated behind the grid at the back of the appliance) guarantees fresh air
during cleaning. It should be replaced approximately every 3 months (depending on the
operating frequency).
Switch off the appliance, open the grid, remove the filter and clean it in soapsuds. When it
is dry, put it back and close back the grid.
NOTE: After a certain number of cleanings the filters will be damaged or impossible to get back
in their initial shape. In such case, please contact the nearest customer service to obtain new
filters.
Cleaning the dust collector
Press the release button of the dust container and pull the dust container out.
Press the unlocking button on top of the handle of the dust collector to remove the lid of
the dust container with the multi-cyclone filters.
Clean the inside of the dust collector and the lid with the multi-cyclone filters with a
damp cloth or sponge, but make sure they are totally dry before using the appliance
again.
When the dust collector and its lid are completely dry, put the lid back on the dust
collector and press until it clicks into place. Put the dust collector back in the appliance
until it locks in place.

PRACTICAL HINTS

When cleaning stairs, we advise you to keep the unit in a vertical position.
The floor brush is equipped with a hook, allowing you to attach the tube to the rear part of
the appliance when it is in use, for instance when you want to move a piece of furniture,
or after use when storing your appliance.
Copies of the I/B. Please reproduce them without any
changes
except
under
International BELGIUM. The pages must be reproduced and
folded in order to obtain a booklet A5 (+/- 148.5 mm width x
210 mm height). When folding, make sure you keep the good
numbering when you turn the pages of the I/B. Don't change
the page numbering. Keep the language integrity.
container)
2 motor filters (on top of the appliance, next to the dust collector)
1 air filter, to vacuum the smallest particles (at the back of the
appliance)
