Make sure the correct poles
are connected on both units
(Fig. 12)
Panel installation.
1. Position the panel on the indoor unit,
positioning the corner of vein motor in
the indoor unit piping corner.
2. Installation of the decorative panel:
All manuals and user guides at all-guides.com
(1) From the tab located on the other side of
the vein motor of the decorative panel,
hang the supplied support temporarily.
(2 positions)
(2) Also hang the two remaining tabs tem-
porarily. Be sure to avoid the vein motor
cable from sticking to the filler material.
(3) Insert and tighten the 4 hexagonal
screws on the right, aprox. below the
�����
����������
�����������
�������
�������������
Fig. 12
(4) Adjust the panel by turning in the direc-
(5) Tighten screws until the distance be-
�������
����������������
�����������
GB
tabs. (The panel will rise 15 mm.)
tions indicated in Fig. A, so as to com-
pletely cover the opening in the ceiling.
tween the indoor unit and the panel is
about 5-8 mm.
���
17
