Diagrama De Cableado - S.R.Smith poolLUX Power pLX-PW60 Instrucciones De Instalación

Tabla de contenido

Publicidad

TRANSFORMER
B
R
Conexiones
eléctricas
12V
Ubicaciones del
cableado de salida
DIAGRAMA DE CABLEA DO
Y
G
W BK
L/V
13V
BK
G
GND
GND
Ubicaciones del
cableado de entrada
11
ON
3b
3a
2b
2a
1b
1a
OFF
NOTAS: A MENOS QUE SE
ESPECIFIQUE OTRA COSA
1. MARCAS DE COLORES
DEL CABLE:
R = ROJO
W = BLANCO
BK = NEGRO
B = AZUL
Y = AMARILLO
G = TIERRA
2. MARCAS DE CONEXIONES
ELÉCTRICAS:
12V = 12VAC
L/V = BAJO VOLTAJE
COMÚN
13V = 13VAC
GND = TIERRA
N = ENTRADA DE
CORRIENTE NEUTRAL
H = ENTRADA DE
CORRIENTE
N
H
