4. Installation of mount

Open the package, take out the product with foam still attached, and gently placeit on a desktop or table.
1
Remove the extra parts and the foam covering the backof the monitor. Press the release button to
remove the stand plate.lf the monitorwas already attached to the stand, remove the stand.
Remove the original screws from the opening on the back of the monitor. Mount the monitor to the wall or
2
fixture as needed. Remember to use the provided wall mounting screws when installing the monitor.
Please place the screws correctly, as shown in the figure below.
Original screws
3 Hang the assembled product on a hard wall. Do not pinch the screen with your hands during the hanging
process to avoid damaging the screen.
Release button
Foam
wall mounting screws
Mount (not included)
ICARUS SERIES
Stand Plate
Use the 27.5mm
Use the 17mm
