Hanna Instruments HI 8510 Manual De Instrucciones

Manual de instrucciones
HI 8510 - HI 8512
HI 8710 - HI 8711
HI 8720 - HI 931500
HI 931501 - HI 932500
Indicadores y
Controladores de
ORP - pH para
su instalación en panel
ORP HI 8720E
mV
DOSAGE
SLOPE
OXID.
REDUC.
∆AL
MEA
SET
SURE
COARSE
SET
∆AL
FINE
0 mV 500 mV
TEST TEST
www.hannainst.cl
Este instrumento cumple las normativas
.
1
E s t i m a d o c l i e n t e :
T h a n k y o u f o r c h o o s i n g a H a n n a I n s t r u m e n t s
P r o d u c t .
P l e a s e r e a d t h i s i n s t r u c t i o n m a n u a l c a r e f u l l y
b e f o r e u s i n g t h e i n s t r u m e n t .
T h i s m a n u a l w i l l p r o v i d e y o u w i t h a l l t h e n e c e s -
s a r y i n f o r m a t i o n f o r t h e c o r r e c t u s e o f t h e
i n s t r u m e n t , a s w e l l a s a m o r e p r e c i s e i d e a o f i t s
v e r s a t i l i t y i n a w i d e r a n g e o f a p p l i c a t i o n s .
T h e s e i n s t r u m e n t s a r e i n c o m p l i a n c e w i t h t h e
directives EN 50081-1 and 50082-1.
TABLA DE CONTENIDOS
Examen preliminar ...................................... 1
Descripción general ..................................... 1
Dimensiones mecanicas ............................. 3
Functional Description HI 8510 .................... 4
Functional Description HI 8512 .................... 7
Functional Description HI 8710 .................. 10
Functional Description HI 8711 .................. 14
Functional Description HI 8720 .................. 18
Functional Description HI 931500 .............. 22
Functional Description HI 931501 .............. 24
Functional Description HI 932500 .............. 27
Specifications HI 8510 and HI 8512 ........... 29
Specifications HI 8710 and HI 8711 ........... 30
Specifications HI 8720 and HI 931500 ....... 31
Specifications HI 931501 and HI 932500 .... 32
Initial Preparation ...................................... 33
Operational Guide ..................................... 36
pH Calibration ........................................... 40
ORP Calibration ........................................ 42
pH Values at Various Temperature ............. 43
pH Diagnostic Tests .................................. 44
ORP Diagnostic Tests ............................... 46
LED Indication ........................................... 47
Taking Redox Measurements .................... 48
Electrode Conditioning and Maintenance ... 51
Suggested Installations ............................. 56
Acesorios .................................................. 58
Garantia .................................................... 64
CE
Declaración de conformidad CE ................ 65
ISO 9000
Certificado Com-
2
pany desde 1992
PRELIMINARY EXAMINATION
Remove the instrument from the packing
material and examine it carefully to make
sure that no damage has occurred during
shipping. If there is any noticeable damage,
notify your Dealer.
Note: Save all packing materials until you
are sure that the instrument functions
correctly. All defective items must be
returned in the original packing materials
together with the supplied accessories.
GENERAL DESCRIPTION
HI 8510, HI 8512, HI 8710, HI 8711, HI 8720,
HI 931500, HI 931501 and HI 932500 are pH-
ORP panel-mounted indicators and control-
lers designed for simplicity of use in a wide
range of industrial process instrumentation.
The models are designed with DIN standard
panel mount with membrane keypads on the
front panel, a large LCD display and
autodiagnostic functions (not HI 931500,
HI 931501 and HI 932500).
Connections to the power supply, contacts
and recorders are made through screw termi-
nals on the rear panel.
Two models are available for HI 8510, HI 8711,
HI 8512, HI 8520. The E-model accepts input
direct from the pH or ORP electrode, while
the T-model accepts a 2-wire current loop of
4 to 20 mA from a pH or ORP transmitter.
HI 931500, HI 931501 and HI 932500 are
equipped with a BNC socket to connect a
pH-ORP electrode.
Other features include: recorder output in 0
to 20 mA or 4 to 20 mA; LED indicators
which identify the controller mode.
