To select the drive control mode:
■ First, check the active mode. Either depress
and release the trigger switch or press the
drive control button or "T" button directly
without touching the trigger switch. The
LED indicator below the mode number
will illuminate to indicate the active mode
setting.
■ Press the drive-control button briefly (less
than 0.5 second) to cycle through the 3
modes. Each press changes one torque
level. See more details in the chart below.
it indicator
displayed on panel
ON OFF
16
Woking
Purpose
mode
Tightening when a good
1
finishing is needed
Tightening with less
force and speed than
2
mode 3 (easier to
control than mode 3)
Tightening with the
3 maximum force and
speed
Driving self-tapping
TI screws into sheet metal
with good finish
Driving self-tapping
screw into thick metal
T2 with good finish
(handing tougher work
compare to T1 mode)
To select the "T" mode:
■ Two methods are available to check the
current T mode:
Either depress and release the trigger switch
or press the drive-control button or the "T"
button directly without touching the trigger
switch.
The LED indicator below the mode number
will illuminate to indicate the current mode
setting.
Press the "T" button briefly (less than 0.5
seconds) to cycle between T1 and T2 modes.
Each press changes one mode. See more
details in chart below:
Example of application
Tightening screws into sensitive
boards, such as plaster boards
Driving screws into hard materials
as well as tightening bolts
Driving long screws into hard
materials, as well as tightening
bigger bolts than mode 2
Recommended type: #4.2x13 mm
Recommended type: #4.8x25 mm
Recommended type:
#5,5x38 mm or 6.3x60 mm
