EN
7-Cell DMX Values
7-Cell RGBAL FULL 96CH / RGBAL Fine 70CH
70Ch 96Ch Function
– 1 Dimmer
– 2 Dimmer fine
1 3 Red 1
2 4 Red fine 1
3 5 Green 1
4 6 Green fine 1
5 7 Blue 1
6 8 Blue fine 1
7 9 Amber 1
8 10 Amber fine 1
9 11 Lime 1
10 12 Lime fine 1
– 13 Virtual Color Wheel 1
– 14 Color Temperature 1
– 15 Strobe 1
11 16 Red 2
12 17 Red fine 2
13 18 Green 2
14 19 Green fine 2
15 20 Blue 2
16 21 Blue fine 2
17 22 Amber 2
18 23 Amber fine 2
19 24 Lime 2
20 25 Lime fine 2
26 Virtual Color Wheel 2
–
– 27 Color Temperature 2
28 Strobe 2
–
21 29 Red 3
22 30 Red fine 3
23 31 Green 3
24 32 Green fine 3
25 33 Blue 3
26 34 Blue fine 3
27 35 Amber 3
28 36 Amber fine 3
29 37 Lime 3
30 38 Lime fine 3
– 39 Virtual Color Wheel 3
– 40 Color Temperature 3
– 41 Strobe 3
31 42 Red 4
32 43 Red fine 4
33 44 Green 4
34 45 Green fine 4
35 46 Blue 4
36 47 Blue fine 4
37 48 Amber 4
38 49 Amber fine 4
39 50 Lime 4
9
QUICK REFERENCE GUIDE
Value Percent/Setting
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 Refer to the
000  255 Refer to the
000  010 No function
011  255 Strobe, slow to fast
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 Refer to the
000  255 Refer to the
000  010 No function
011  255 Strobe, slow to fast
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 Refer to the
000  255 Refer to the
000  010 No function
011  255 Strobe, slow to fast
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
Virtual Color Wheel Chart
Color Temperature Chart
Virtual Color Wheel Chart
Color Temperature Chart
Virtual Color Wheel Chart
Color Temperature Chart
Ovation B-1965FC QRG Rev. 10
section for specific values
section for specific values
section for specific values
section for specific values
section for specific values
section for specific values
