(5) Separate the push lever from the workpiece.
Next, point the nailer downward, pull the trigger and
then wait in that position for 5 seconds or longer.
THE NAILER MUST NOT OPERATE.
Pull trigger
(6) Without touching the trigger, depress the push lever
against the workpiece.
Pull the trigger.
THE NAILER MUST OPERATE.
(7) If no abnormal operation is observed, you may load
nails in the Nailer.
Drive nails into the workpiece that is the same type to
be used in the actual application.
THE NAILER MUST OPERATE PROPERLY.

LOADING NAILS

WARNING
When loading nails into Nailer,
1) do not depress trigger;
2) do not depress push lever; and
3) keep Nailer pointed downward.
2–Action Nail Feeding!
(1) Insert nail strip into the back of the magazine.
(2) Slide the nail strip forward in the magazine.
Magazine
— 17 —
(3) Pull the nail feeder (B) back to engage the feeder knob
to the nail strip.
Nail feeder (B)
NOTE:
Quietly push the nail feeder (B) and feeder knob against
the nail.
If the nail feeder (B) and feeder knob are released from
backward the magazine and bumped against the nail, the
connecting paper or plastic of the nail can be damaged.
Use an unbroken nail strip with nails of all the same
length.
The Nailer is now ready to operate.
Removing the nails:
1 Pull the feeder knob backward.
2 Return the feeder knob forward quietly while pushing
the nail feeder (B).
3 Push the nail stopper.
4 Pull out nails from the back of the magazine.
Nail feeder (B)
Nail stopper
English
Feeder knob
Feeder knob
Nail
