Denon AH-D2000 Instrucciones De Funcionamiento

CLOSED TYPE STEREO
HEADPHONES
AH-D2000
OPERATING INSTRUCTIONS
BEDIENUNGSANLEITUNG
MODE D'EMPLOI
ISTRUZIONI PER L'USO
INSTRUCCIONES DE
FUNCIONAMIENTO
GEBRUIKSAANWIJZING
BRUKSANVISNING
操作說明書
操作說明書
A
B
C
Slider
Stellbügel Ohrmuschel
Glissière
Elemento scorrevole
Hanger
Aufhängung
Attache
Attacco
Housing Hanger
Aufhängung
Corps Attache
Cuffia Attacco
Accessories
Check that the following parts are attached in
addition to the main unit:
q
Operating instructions ......................................1
w
Standard conversion plug (
Declaration of conformity
We declare under our sole responsibility that this
product, to which this declaration relates, is in
conformity with the following standards:
EN55013 and EN55020.
Following the provisions of 89/336/EEC and
93/68/EEC Directive. (For Europe model)
A note about recycling
This product's packaging materials are
recyclable and can be reused. Please
dispose of any materials in accordance
with the local recycling regulations.
When discarding the unit, comply with
local rules or regulations.
This product and the supplied accessories conform
to the WEEE directive. (For Europe model)
Safety precautions
• Listening at high volumes that irritate your ears
can have a negative influence on your hearing.
• Do not use headphones while driving a bicycle,
motorcycle or automobile. Doing so could lead to
accidents.
• When using headphones, for safety keep the
volume to a level at which surrounding sounds
can be heard.
• Do not put in water or dampen.
• Do not place heavy objects on, heat, or pull on
the headphones. Doing so could damage or
deform them.
• To prevent injury, be careful not to let your fingers
get caught between the housing and hanger.
Caution on handling
• Be sure to hold the plug when unplugging the
cord.
• The ear pads may deteriorate after extended
usage or storage.
• Always keep the headphones (particularly the ear
pads) clean. If they are dirty, this may reduce their
performance. Use a soft cloth to gently wipe off the
dirt.
• Do not use benzene, thinners, or other organic
solvents or insecticides on the main unit since
they may cause a change in quality or color.
• The headphones have a structure by which the
sound tends to leak out if the volume is too high.
Be considerate of others.
• Holding the hanger as shown in the diagram,
open slowly and mount. Be careful not to get
your fingers caught in the hanger when
mounting. ( B)
Using the headphones
• Check the markings on the housing, and place
the headphones over your head so that the
housing marked "R" is over the right ear, the one
marked "L" over the left ear.
• The slider can be adjusted in 7 steps. Set to the
position that suits you best. (
Specifications
¢ Type:
¢ Drive units:
¢ Input impedance:
¢ Sensitivity:
¢ Maximum input:
¢ Playback frequencies: 5 ~ 45,000 Hz
¢ Mass:
¢ Cord length:
¢ Plug:
* For improvement purposes, specifications and
design are subject to change without notice.
ENGLISH
A)...................1
C)
Dynamic type
φ 50 mm
Neodymium magnet
25 Ω/ohms
106 dB/mW
1,800 mW
350 g
(not including cord)
3.0 m OFC cord
φ 3.5 mm gold-plated
stereo mini plug
