2 Overview

2.1 Controls and components

1. Charge indicator LED lights
2. Power Adjustment button
3. On/off button
4. Emptying dust container ring
5. Dust container
6. Tube release button
7. Appliance release button
8. Charging Dock
9. Accessory attachment parts
10. Tube
11. Brush release button
12. Electric turbo brush
13. Charging adaptor
14. Mini turbo brush
15. Dust brush
16. Crevice attachment
17. Screw (4 pcs)
18. Dowel (4 pcs)
The values provided with the appliance or its accompanying documents are laboratory readings in
accordance with the respective standards. These values may differ depending on the use and ambient
conditions.
8 / EN

2.2 Technical data

Nominal input power: 150 W:
Input:
100 - 240 V~ 50-60 Hz 0,5 A
Output: 32 V
Charging time: 4-6 hours
Runtime at max. power: 17 mins
Runtime at min. power: 45 mins
The rights to make technical and design changes
are reserved.
External Power Supply Parameter
Manufacturer:
Guangdong Huachuangxing Power Supply
Co.,Ltd
Model ID: HCX1501-3200450E
Input Voltage: 100-240V~
Input Frequency: 50-60Hz
Input Current: 0.5A
Output Voltage: 32.0V
Output Current: 0.45A
Output Power: 14.4W
Average active efficiency: 85.68%
Efficiency at low load (10%): 79.19%
Power consumption under no load: 0.08W:
Vertical Cordless Vacuum Cleaner / User Manual
0.45 A
