Operation
Starting the Edger
1. Align the cavity in the battery pack with the
tongue on the handle housing
2. Push the battery pack into the handle until the
battery locks into the latch
1. Battery latch
3. To start the edger, pull back on the lockout
button, then squeeze the run trigger
Note:
Once the edger is running you can
release the lockout button.
1. Lockout button
(Figure 7).
(Figure 7).
Figure 7
(Figure
Figure 8
2. Run trigger
Shutting Off the Edger
To shut off the trimmer, release the trigger.
Whenever you are not using the edger or are
transporting the edger to or from the work area,
remove the battery pack.
Removing the Battery Pack
from the Trimmer
Press the battery latch on the machine to release the
battery pack and slide the battery pack out of the
machine (Figure
g333238
8).
1. Battery latch
g333239
12
9).
Figure 9
g333240
