Audio Connection - Panasonic VIERA TC-60PU54 Manual De Usuario

To use HDMI terminals
Best
Connect to Audio
input terminal
To use COMPONENT terminals
Good
To use COMPOSITE terminals
Basic
(Not HD)
●
The Green terminal is shared for both the COMPONENT and COMPOSITE (VIDEO IN) connection.
When using COMPOSITE (VIDEO IN) connection, the Yellow connector (Video) should be inserted into Green
connection.
AV cable connection
HDMI-DVI
Conversion cable
red
blue
green
white
red
yellow
white
red

Audio connection

Optical cable
HDMI
AV OUT
DVI OUT
L
AUDIO OUT
R
Y
green
green
P
COMPONENT
B
VIDEO OUT
blue
blue
P
R
red
red
L
AUDIO
white white
OUT
R
red red
yellow
yellow
L
COMPOSITE
white
white
OUT
R
red
red
Audio equipment
DIGITAL
AUDIO IN
e.g. Amplifier
AV Equipment
e.g. Blu-ray Disc
player
AV Equipment
e.g. Blu-ray Disc
player
AV Equipment
e.g. Blu-ray Disc
player
AV Equipment
e.g. DVD Recorder
or
e.g. VCR
11
