Care And Maintenance - DeWalt DXF1645 Traducido De Las Instrucciones Originales

Adjustment knob
1
Adjustment knob pad
3
Cradle base
5
•
Align and insert the
and , tighten them with the
3
-tighten. Repeat above process for the
opposite side of fan.
•
Press the into the back hole on
5
tighten the on each side of the
6
Fan Operation:
3.
the cradle in its upright position. The fan itself can
be tilted into various positions depending on
applications, including straight upward.
Fan Location:
4. Place the fan in an area in
the room that will provide the most effective
air circulation.
Fan Connection:
5.
to connect to the power cord adapter as shown
in Fig C. Plug the power cord into the appropriate
outlet. Be sure plug ts tightly in outlet. A loose
connection may cause overheating and damage
to the plug or fan.
NOTE:
To prevent overloading a circuit, do not
plug the fan into a circuit that is servicing other
electrical needs.
6.
Turning Fan On:
surface. Plug fan into properly grounded outlet.
To start the fan, turn the switch from the OFF
position to the desired fan speed.
7.
Turning Fan Off:
the switch from the current fan speed setting
to the off position. Remove plug from outlet.
8.
Adjusting Fan Tilt:
knob until the drum rotates freely on the frame.
Adjust the fan to desired tilt angle and re-tighten
the knob. Do not overtighten adjustment knob.
SUSPENDING/MOUNTING
THE FAN
CAUTION:
When the fan hangs by the hang
hooks, do not shake the fan or the object from which
it hangs. Do not hang the fan from any electrical wires
or anything that is not secure. Personal injury or
property damage may occur.
CAUTION:
Only use the hang hooks for hanging
the fan as shown in Fig. B. The hang hooks are not
intended to support additional weight. Do not attach
or hang anything additional to the fan or risk of
breakage may occur.
Foot support
2
Drum
4
Screw
6
to the side hole on
2
1
. Do not over
4
, then
2
.
2
Always operate the fan with
Select the appropriate plug
Place fan on stable level
To turn the fan off, turn
Loosen the adjustment
CAUTION:
Do not use the hang hooks to reach
with or to support your weight in any situation.
CAUTION:
Do not stand underneath the fan
when it is mounted overhead. Serious personal injury
or damage to the fan may result if the fan falls.
CAUTION:
Do not mount the fan to the ceiling.
NOTE:
Locate the fan away from a corner or other
obstructions which may impede air ow. Your jobsite
fan has multiple options for mounting.
HANG HOOK
The built-in hang hooks telescope out of the back legs
and can be used to suspend the fan from 2X lumber
as shown in Fig. B. Be sure to fully extend the hooks
before using, then rotate as needed.

CARE and MAINTENANCE

Cleaning:
WARNING:
Before cleaning the fan be sure to
disconnect power cord from the plug. Clean the grill
surface with a clean damp cloth. Do not use harsh
chemical or abrasive cleaners.
WARNING:
DO NOT IMMERSE THE FAN OR ANY
WIRES IN WATER. Replace front grill before fan use
and allow fan to dry completely before use. Periodic
grill cleaning with a vacuum will prevent dust build up.
The motor is sealed and does not require any interior
maintenance, cleaning or lubrication.
Maintenance:
The Internal motor bearings are
permanently lubricated at the factory and do not require
any additional lubrication.
Repair:
WARNING:
DO NOT OPERATE THE FAN
WITHOUT THE GRILL IN PLACE. DO NOT USE THE
FAN IF IT HAS MALFUNCTIONED OR BECOME
DAMAGED IN ANY WAY.
Storage:
Keep original carton for storage of the fan.
Coil and tie the power cord to avoid damage during
storage.
Protecting the environment
Separate collection. Products and batteries
marked with this symbol must not be
disposed of with normal household waste.
Products and batteries contain materials that can be
recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and
batteries according to local provisions. Further
information is available at www.2helpU.com
4
English
