Nobles Power Eagle 1016 Manual Del Operador página 25

REF PART # DESCRIPTION
∇
DASSEMBLY, LID
1 100103
2 600812 LID, OUTER RING
Y
Y 3 100105 LID, CENTER
4 140900 SCREW, 10–24X3/4
5 602715 BLADDER, TANK
6 120906 DECAL, IMPORTANT–DRAIN
7 602448 STAND PIPE
DFLOAT, SHUT–OFF
8 180613
9 606088 FITTING, 1–1/2" NIPPLE CPVC
10 230159 O–RING
11 210240 NUT, FLANGED METAL 1–1/2 FPT
∇
602497 ASSEMBLY, DOME
Y 12 100112 DOME, VACUUM
Y 13 240217 KNOB, DOME
Y 14 140037 WASHER, NYLON
DGASKET, RECOVERY DOME
Y 15 100042
Y 16 230834 FITTING 1–1/2SX1–1/2S45 PVC–40
DHOSE, VAC, 11/2"X53" W/ CUFFS
17 160464
∇ 18
DASSEMBLY, DRAIN PLUG
701061
Y 19 230831 KNOB, DRAIN HOSE
DSTRAP, RUBBER
Y 20 230882
Y 21 140056 WASHER, FENDER
Y 22 140955 PLUG, DRAIN HOSE
23 140921 SLEEVE, DRAIN HOSE
24 140072 CLAMP
∇ ASSEMBL
Y
INCLUDED I N A S S E M B L Y
Y
D RECOMMENDED S T O C K I T E M S
∇ CONJUNT O
INCLUIDO E N E L C O N J U N T O
Y
D AR T ICULOS R E C O M E N D A D O S P A R A M A N T E N E R E N E X I S T E N C I A
Power Eaglet 1016/1020 (09–01)
RECOVERY TANK GROUP
CONJ. DEPOSITO RECUPERAR
QTY.
1
1
1
6
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
2
Home Find... Go To..
REF PART # DESCRIPTION
25 160416 HOSE, DRAIN
26 140307 CLAMP, HOSE
27 611978 BRACKET, HOSE HGR.
28 140826 SCREW, #6X3/4
29 230844 BRACKET W/ HOLES, TANK
BRACE
30 230843 BRACKET W/ THDS, TANK BRACE
31 140259 SCREW, 1/4–20X5/8
32 230955 CLAMP, TANK BRACE
33 140553 SCREW, 1/4–20X1/2
34 140016 WASHER, 1/4 LOCK
35 140000 WASHER, FLAT
36 102569 GASKET, TANK
37 140227 SCREW, STUD, 1/4–20X5
38 608504 DECAL, POWER EAGLE 1016
608528 DECAL, POWER EAGLE 1020
39 608186 DECAL, NOBLES LOGO
40 608532 TANK, RECOVERY, GREEN
DHOSE, CLEANOUT 1.5"X36"
41 160424
DCORD, 16/3X50' YELLOW (120V)
42 130250
43 120907 DECAL, IMPORTANT –
ALWAYS CLOSE
44 120399 DECAL "DO NOT ALLOW FOAM"
45 140000 WASHER, FLAT
PARTS LIST
LISTA DE PIEZAS
QTY.
1
1
1
2
1
1
1
1
1
2
2
1
3
2
2
1
1
1
1
1
1
6
25
