FPZ K03-MS Manual De Uso página 6

DIMENSIONS
DIMENSIONES
DIMENSIONS
INGOMBRI
Dimensions in in, Medidas in in, Dimensions en in, Misure in in
Model a
K03-MS 9.49
K04-MS 11.22
K05-MS 12.87
K06-MS 14.80
Model I
K03-MS 3.39
K04-MS 4.02
K05-MS 4.72
K06-MS 4.92
Model s
K03-MS 0.16
K04-MS 0.16
K05-MS 0.16
K06-MS 0.16
FPZ-MI-K-MS-MOR-USA-15-R03
b c
10.55 5.79
12.40 6.77
14.37 7.87
15.47 8.07
m n
0.39 3.27
0.47 3.74
0.59 4.53
0.59 5.51
t u
M6 5.51
M6 6.89
M8 7.87
M8 9.45
d e
1.69 9.06
1.93 10.04
2.13 12.60
2.13 12.80
o p1
5.59 8.07
6.73 8.74
10.43 12.60
10.71 13.15
v w
7.09 7.40
7.68 7.40
12.99 11.22
13.07 11.22
6 / 84
(K03-MS/K04-MS/K05-MS/K06-MS)
f G H max
8.07 1" 1/2 NPT
8.86 1" 1/2 NPT
10.24 2" NPT
11.42 2" NPT
p2 q
5.51 0.71
6.30 0.71
9.06 0.71
9.61 0.71
x
4.17 0.47
4.72 0.71
7.24 0.75
7.80 0.75
11.97
13.78
14.40
14.45
r
2.95
2.76
3.86
3.35
z
