Definition of terms

V volt
A ampere
Hz hertz
W watt
kW kilowatt
g gram
kg kilogram
Bj year of
manufacture
Pos : 20 /RVT/Besc hrei bung/Symbol e auf dem Ger ät/AC O202XL/Bruc hstüc ke, Quetschg efahr, Wartung, H altebolzen @ 0\mod_1380702165067_18.doc x @ 1160 @ 1 @ 1
4

Symbols on the device and information on the rating plate

Symbol Meaning
Warning − ejected fragments
Warning: Danger of crushing
Service sticker; indicates when the next service is due.
Using the retaining pin
Pos : 21 /RVT/Besc hrei bung/T ypens chil d/T ypensc hild - AC O203XL @ 1\mod_1447337569516_18.doc x @ 15348 @ @ 1
Information on the rating plate
Pos : 22 /RVT/Besc hrei bung/Pi ktogramme auf T ypensc hild/200, 300, 400er R eihe/Pi ktogramme auf T ypenschil d-200, 300, 400er @ 1\mod_1438249957962_18.doc x @ 13670 @ @ 1
Explanation of possible pictograms on the rating plate
Verification marking Canada/
USA
Verification marking Canada/
USA
Registration of products on the
uniform customs territory.
Verification marking Australia
Pos : 23 /RVT/Allgemeines /#### Seitenumbr uch #### @ 0\mod_1380200837280_0.doc x @ 885 @ @ 1
Ah ampere hour
db(A) decibel (sound pressure)
bar bar
°C degree Celsius
kN kilonewton
a.c. Alternating current voltage
d.c. Direct current voltage
F force
1 Manufacturer logo incl.
address
2 Permissible uninterrupted
operating time
3 Part No.
4 Serial No.
5 Year of manufacture
mm.yy
13
ACO203XL
Ø diameter
h hour
min minute
s second
m/s² metre divided by
square second
(acceleration)
Nr number
6 Power consumption
7 Country of manufacture
8 Permissible voltage range
in volt
9 Nominal force
10 Type designation of
device
CE conformity marking product
safety in Europe
Protection class II (insulated
housing)
Read Operating Manual
