Compressor
EE 07 current
protection
Communication
failure between
EE 08
the controller and
the main board
Communication
failure between
EE 09
Main board and
driver board
VDC voltage too
EE 10
high protection
IPM module
EE 11
protection
VDC voltage too
EE 12
low protection
Input current over
EE 13
high protection.
IPM module
EE 14 thermal circuit is
abnormal
Temperature of
EE 15 IPM module is too
high
1. The compressor current is too large
momentary
2. Wrong connection for compressor
phase sequence
3. Compressor accumulations of liquid and
oil lead to the current becomes larger
4. Compressor or driver board damaged
5. The water flow is abnormal
6. Power fluctuations within a short time
1. Poor signal wire connection or
damaged signal wire
2. Controller malfunction
1. Poor connection of communication wire
2. The wire is damaged
1. Mother line voltage is too high
2. Driver board is damaged.
1. Data mistake
2. Wrong compressor phase connection
3. Compressor liquid and oil accumulation
lead to the current becomes larger
4. Compressor or driver board damaged
1. Mother line voltage is too low
2. Driver board is damaged.
1. The compressor current is too large
momentary
2. The water flow is abnormal
3. Power fluctuations within a short time
4. Wrong PFC inductor
1. Output abnormity of IPM module
thermal circuit
2. Fan motor is abnormal or damaged
3. Fan blade is broken
1. Output exception of IPM module
thermal circuit
2. Motor is abnormal or damaged
3. Fan blade is broken
1. Check the compressor
2. Check the waterway system
3. Check if the power in the normal
range
4. Check the phase sequence
connection
1. Check and re-connect the signal
wire
2. Change a new signal wire
3. Turn off electricity supply and
restart machine
4. Change a new controller
1. Check the wire connection
2. Change a new wire
1. Check if the power is in the normal
range
2. Change driver board or main board
1. Program error, turn off electricity
supply and restart after 3 minutes
2. Change driver board
3. Check compressor sequence
connection
1. Check if the power is in the normal
range
2. Change driver board
1. Check the compressor
2. Check the waterway system
3. Check if the power is in the normal
range
4. Check if the correct PFC inductor is
used
1. Change a driver board
2. Check if the motor speed is too low
or fan motor damaged, change
another one
3. Change another fan blade
1. Change a driver board
2. Check if the fan motor speed is too
low or fan motor damaged, change
another one
3. Change another fan blade
