ATTACHING BATTERY PACKS (See drawings)
1. Slide Battery Pack Wire Clip SECURELY over boot top (see point 2
below), boot or shoe laces, or attach to strap such as Velcro® power
strap on ski or snowboard boot.
2. NOTE: DO NOT SLIDE BATTERY PACK OVER SLIPPERY
MATERIAL SUCH AS SKI BOOT PLASTIC AS THE EASIER IT SLIDES
ON, THE EASIER IT WILL SLIDE OFF. SECURELY ATTACH
BATTERY PACK AT ALL TIMES.
3. Mounting Bracket Accessory (optional). For simple, secure, quick
attachment of Battery Packs to ski or hard shell snowboard boots.
4. Strap Bracket Accessory (optional). For simple, secure, quick
attachment of Battery Packs to ski or snowboard boot power straps.
5. Slide Strap Bracket Accessory (optional). For Battery Pack Power
Plus m4 and m3 only. Provides simple, secure, quick attachment of
Battery Packs to ski or snowboard boot power straps.
6. Velcro® Attachment Strap Accessory (optional). Strap around leg at
or above calf or around boot top. Battery Pack clips over Strap.
7. Extension Cord Accessory (optional). Run Cord underneath pant leg
and plug into Battery Pack at waist height (80 cm Cord) or chest
height (120 cm Cord).
POSITIONING BATTERY PACKS (SKI & SNOWBOARD BOOTS)
1. Positioning Battery Pack HIGH on back of boot permits pant leg to
cover Battery Pack but increases potential chair lift damage.
2. Positioning Battery Pack LOW on back of boot reduces potential
chair lift damage but increases potential damage while walking
down stairs.
3. Positioning Battery Pack on TOP FRONT of boot permits pant leg to
cover Battery Pack, eliminates potential chair lift and stair damage,
and is convenient when adjusting setting.
4. Positioning Battery Pack on TOP LATERAL SIDE of boot (see Strap
Bracket and Slide Strap Bracket drawings) permits pant leg to cover
Battery Pack, eliminates potential chair lift and stair damage, and is
convenient when adjusting setting.
• CAUTION: Use Hotronic's White Plug Recharger ONLY for Power
Plus m4 and Power Plus m3 Battery Packs. Using other than
Hotronic's White Plug Recharger voids Warranty.
• Hotronic's White Plug Recharger detects when batteries are fully
charged and automatically switches to trickle current recharging after
approximately 3 hours or less of full current recharging. Recharger
accepts electric input ranging from 100-240VAC, 50-60Hz.
• While not required of NiMH batteries, Hotronic recommends an
occasional full discharge before fully recharging to help maintain
optimal strength. Use "continuous setting 4" for quickest discharge.
Battery Packs are fully discharged when Heating Elements are no
longer warm and all LEDs are off.
NOTE: Hotronic recommends recharging when Battery Packs are off.
(Battery Packs are off when all LEDs are off.) However, Battery Packs
MAY be recharged at any setting. If recharging while on setting 1, 2,
3, or 4, DO NOT CHANGE SETTING DURING RECHARGING as this
may cause recharging process to stop.
1. Plug Recharger into wall outlet using correct plug adapter (North
American, European, or other).
a. Recharger performs short self-test with brief red LED followed by
brief green LED and then LED off.
2. Attach each Battery Pack to Recharger.
3. Recharger LED is continuous red when detecting Battery Pack status.
4. Recharger LED is continuous red during initial current and full
current recharging.
(See drawings)
RECHARGING BATTERY PACKS
- 9 -
