Description of device

The individual parts of the generator are shown and named in the diagram below. These
terms are used throughout the operating instructions.
6
7
No. Component description
1 Piezo crystal (internal)
2 Nozzle insert
3 Catch button for nozzle insert (on both sides)
4 On / Off button
5 Nameplate
6 Fan grille
7 Socket for external power plug
BA-PZ2_ML / F0351301
