Output Indicator
Illuminates to show that the power station is in the discharging process when the AC/
USB button is switched on.

Charging Indicator

Illuminates to show the power station is in the charging process.
Charge-complete Indicator
The charge-complete indicator, together with the charging indicator will illuminate to
indicate that the charging is completed.
Actual Output Power Indicator
Illuminates different numbers of the segments to indicate the actual output power
when a device is connected to the output port.
Rated Power Indicator (600W, 1200W, 2000W)
The rated maximum continuous output power depends on the attached battery(s) on
the Nexus power station.
Peak-power Indicator (3000W)
When the actual output power is over 2000W, but less than 3000W, for LESS THAN
3 seconds, this indicator will illuminate, as well all the segments of the actual output
power.

Overload Indicator

This indicator is separated into 3 segments. When the actual output power is over the
rated power, the corresponding segment will illuminate in red. The overload reminder
"PRESS AND HOLD RESET BUTTON" and the warning indicator " " will illuminate in
red at the same time. Remove the device and then press and hold the reset button to
reactivate the power station.
