TRC 3
GB
– Protect the device against water.
– Protect the cable against heat, oil and
sharp edges..
– Check the plug and the cable regularly and
should either become damaged, have
them replaced by an authorised after-sales
service workshop.
5
Operation
5.1
Charging the battery pack
X
To charge the battery pack, slide all the
way onto the retainer
er.
X
To remove, slide off the charged battery
pack in similar fashion.
All Festool battery packs of the series BPS
and BPC can be loaded with the charger. The
charger automatically detects the type of the
inserted battery (NiCd, NiMH or Li Ion). A mi-
croprocessor controls the charging process in
line with the charging state, temperature and
voltage of the battery pack. If a warm NiMH
battery pack (> 37 °C) is inserted, the pack
is charged with a reduced charging current
and will take longer to charge.
The LED
[1-2]
on the charger indicates the
respective operating status of the charger.
LED yellow - lit continu-
ously
Charger is ready to use.
LED green - flashing
quickly
Battery pack is charged to
maximum capacity.
LED green - flashing
slowly
Battery pack is charged with
reduced current. LiIon is
charged to 80 %.
LED green - lit continu-
ously
Charging is complete or is not
restarted as current charge
status is greater than 80%.
LED red - flashing
General fault display, e.g.
incomplete contact, short cir-
cuit, defective battery pack,
etc.
10
[1]
[1-1]
on the charg-
LED red - lit continuously
Battery temperature is out-
side the permitted range.
5.2
Charger wall mounting TRC 3
There are two elongated holes on the back of
the TRC 3 for mounting the charger to a wall
using two screws (e.g. round head or flat
head screw with shank diameter of 5 mm).
X
Insert the two screws into the wall at a
distance of 96 mm from one another and
leave the screw heads protruding approx.
4 mm.
6
Service and maintenance
Observe the following instructions:
– Keep the air slits on the machine and the
charger free and clean to ensure adequate
cooling.
– Keep the contacts on the machine, charger
and battery pack clean.
7
Disposal
Do not throw the tool in your household
waste!! Dispose of machines, accessories
and packaging at an environmentally re-
sponsible recycling centre. Observe the valid
national regulations.
EU only: European Directive 2002/96/EC
stipulates that used electric tools must be
collected separately and disposed of at an
environmentally responsible recycling cen-
tre.
8
Warranty
We offer a warranty for material and produc-
tion defects for all our tools in accordance
with the locally applicable legal provisions,
but for a minimum of 12 months. Within the
EU member states, the warranty period is 24
months (verification through invoice or deliv-
ery note). Damage caused by the operator,
natural wear, overloading, incorrect handling
or through the use of the equipment not
specified in the operating manual, or damage
which was known at the time of purchase, is
not covered by the warranty. Furthermore,
damage caused by the use of non-original
accessories and consumable materials (e.g.
sanding pads) is also excluded.
Complaints can only be accepted if the tool is
returned while still assembled to the supplier
or an authorised Festool Customer Service
workshop. Keep the operating manual, safe-
