ExPLoDED DRAwIng BRAcKET:
1
2
Wall mount panel
1
M6 bolt
2
U-Bracket
3
4 Washer
Wing nut M8
5
16
3
4
5
6
7 8 9
Rubber washer
6
Allen screw M6 x 16
7
8 Spring washer
Metal washer
9
LD SAT Cabinet
10
