Tren De Impulsión Y Unidad De Extremo Deslizante De Cruzbelt 4 - TGW CRUZ 1195753 Manual De Instalación, Operación Y Mantenimiento

CRUZ belt IOM
®
11.23.2 Tren de impulsión y unidad de extremo deslizante de CRUZbelt 4
BALLOON# 40
FPM SIDE DRIVE TRAIN PN
-- 1192976
*38 LH 1192987
RH 1192983
-- 1192977
*45 LH 1192990
RH 1192984
-- 1192979
*57 LH 1192991
RH 1192985
-- 1192981
*76 LH 1192989
RH 1192986
-- 1187672
91 LH 1190104
RH 1190098
-- 1187673
114 LH 1190105
RH 1190099
-- 1187674
127 LH 1190106
RH 1190100
-- 1187675
152 LH 1190107
RH 1190101
-- 1187678
180 LH 1190108
RH 1190102
-- 1187679
229 LH 1190109
RH 1190103
* For normal; speeds of 38 thru 76 FPM, Use 0.50, 0.75-HP NORD STANDARD EFF. MOTORS.
On Brake motors, use 460VAC brake supply voltage that outputs 205VDC to the brake coil.
N.° de pieza: 1195753
REPLACEMENT PART NUMBERS FOR CZB4-EDR DRIVE TRAIN ITEM #s
DRIVE TRAIN ITEM #s / GEARMOTOR PART #s
FOR CRUZBELT 4 END DRIVES
40 2
BRAKE
MOTOR PN MOTOR HP
OPTION
--- 1192973
BRAKE 1192975
BRAKE 1192974
--- 1192973
BRAKE 1192353
BRAKE 1192974
--- 1190384
BRAKE 1192353
BRAKE 1192352
--- 1190384
BRAKE 1192975
BRAKE 1192352
--- 1187037
BRAKE 1190117
BRAKE 1190114
--- 1187037
1190117
BRAKE
1190114
--- 1187037
1190117
BRAKE
1190114
--- 1187038
1190119
BRAKE
1190118
--- 1187039
1190119
BRAKE
1190118
--- 1187039
1190121
BRAKE
1190120
Rev: 20/04/2017
2 1
REDUCER PN
.5 E0038752
.5 E0038752
.5 E0038752
.75 E0039000
.75 E0038419
.75 E0039000
1 E0038491
1 E0038705
1 E0038491
1 E0038705
1 E0039000
1 E0038705
1 E0038710
1 E0038707
1 E0038706
1.5 E0038711
1.5 E0038708
2 E0038709
1
RATIO / HP
BELT PULL
MTR FRAME
60:1, .5HP 56/20H
60:1, .5HP 56/20H
60:1, .5HP 56/20H
50:1, .5HP 56/20H
40:1, .75HP 56/20H
50:1, .5HP 56/20H
40:1, .75HP 56/20H
30:1, .75HP 56/20H
40:1, .75HP 56/20H
30:1, .75HP 56/20H
50:1, .5HP 56/20H
30:1, .75HP 56/20H
25:1, 1HP 140/20H
20:1, 1HP 140/20H
18:1, 1HP 140/20H
15:1, 1.5HP 140/20H
12.7:1, 1.5HP 140/20H
10:1, 2HP 140/20H
REF DWG#: 21A603D & 21A592D
Página 103 de 109
700
583
466
350
291
233
210
261
221
233
