HQ-Power VDPL121RGB Manual Del Usuario página 5

7 Auto run
8 Sound activation – colour change
5-9 Sound activation – light output change
9 RGB colour effect - random
6-9 Red run effect
7-9 Green run effect
8-9 Blue run effect
6-7-9 RG run effect
6-8-9 RB run effect
7-8-9 GB run effect
6-7-8-9 RGB run effect
7. DMX512 Mode
Operation through a DMX controller allows you create own programs:
• Connect a controller with a standard DMX cable.
• Switch on DIP switch 10; set the address with DIP switches 1 to 9.
Channel
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
• DMX512 Connection
Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other side to the male 3-
pin XLR input of the VDPL121RGB. Multiple VDPL121RGBs can be linked through serial linking. The linking cable
should be a two-core screened cable with XLR input and output connectors.
• DMX512 Chain with Termination
VDPL121RGB
Function From
Strobe function
Red
Green
Blue
Red – part 1
Green – part 1
Blue – part 1
Red – part 2
Green – part 2
Blue – part 2
Red – Part 3
Green – part 3
Blue – part 3
Red – Part 4
Green – part 4
Blue – part 4
Colour effects
A DMX terminator is recommended for installations where the DMX cable has to run a
long distance or is in an electrically noisy environment (e.g. discos). The terminator
prevents corruption of the digital control signal by electrical noise. The DMX terminator is
simply an XLR plug with a 120 resistor between pins 2 and 3, which is then plugged into
the XLR output socket of the last device in the chain.
Please see illustrations.
To Description
0 0 ON
1 255 From slow to fast
0 255
0 255
0 255
0 255
0 255
0 255
0 255
From 0 – 100 % output
0 255
0 255
0 255
0 255
0 255
0 255
0 255
0 255
0 255 Random effect from fast to slow
5
4-3-2-1 ON
4-3-2-1 ON
4-3-2-1 ON
4-3-2-1 ON
4-3-2-1 ON
4-3-2-1 ON
4-3-2-1 ON
4-3-2-1 ON
4-3-2-1 ON
4-3-2-1 ON
4-3-2-1 ON
