Altronix ALTV2416 Serie Guia De Instalacion página 11

1.25"
(31.75mm)
1"
(25.4mm)
8.13"
(206.5mm)
1"
(25.4mm)
1.25"
(31.75mm)
3.85"
(97.79mm)
ALTV2416 Series
Dimensiones de el gabinete (H x W x D) para:
• ALTV2416300M • ALTV2416300CBM
8.5" x 7.5" x 3.75" (215.9mm x 191mm x 95mm)
0.6"
(15.24mm)
0.9"
(22.86mm)
0.6"
(15.24mm)
1"
(25.4mm)
3.63"
(92.2mm)
7.25"
(184.15mm)
0.6"
(15.24mm)
0.6"
(15.24mm)
7.25"
(184.15mm)
1.25"
(31.75mm)
3.85"
(97.79mm)
0.9"
(22.86mm)
8.13"
(206.5mm)
3.85"
(97.79mm)
1"
(25.4mm)
1"
(25.4mm)
1.25"
(31.75mm)
1"
(25.4mm)
1.75"
(44.45mm)
1"
(25.4mm)
- 11 -
