Instalación eléctrica
CUSTOMER
1
SUPPLIED 24V RET.
CONTROL CARD PIN 20
1
(TERMINAL JUMPERED TOGETHER)
1
CUSTOMER
2
SUPPLIED 24V
3
CUSTOMER SUPPLIED
(TERMINAL JUMPERED TOGETHER)
3
3
10 MCB 113 PIN X46/1
11 MCB 113 PIN X46/3
12 MCB 113 PIN X46/5
13 MCB 113 PIN X46/7
14 MCB 113 PIN X46/9
15 MCB 113 PIN X46/11
16 MCB 113 PIN X46/13
17 MCB 113 PIN 12
18 CONTROL CARD PIN 37
30 TB08 PIN 01
31 TB08 PIN 02
32 TB08 PIN 04
33 TB08 PIN 05
34 MCB 113 PIN X47/1
35 MCB 113 PIN X47/3
36 MCB 113 PIN X47/2
37 MCB 113 PIN X47/4
38 MCB 113 PIN X47/6
39 MCB 113 PIN X47/5
40 MCB 113 PIN X47/7
41 MCB 113 PIN X47/9
42 MCB 113 PIN X47/8
50 CONTROL CARD PIN 53
51 CONTROL CARD PIN 55
60 MCB 113 PIN X45/1
61 MCB 113 PIN X45/2
62
MCB 113 PIN X45/3
63 MCB 113 PIN X45/4
90
MCB 112 PIN 1
91 MCB 112 PIN 2
TB7
Ilustración 4.22 Diagrama que muestra todos los terminales eléctricos con la opción NAMUR
MG11F505
Manual de funcionamiento
118 117
+ -
REGEN
TERMINALS
TERMINALS
2
TB3 INVERTER 1
1
TB3 INVERTER 1
TB3 INVERTER 2
2
TB3 INVERTER 2
AUX FAN AUX FAN
L1 L1
L2 L2
100 101 102 103
Danfoss A/S © 08/2014 Reservados todos los derechos.
1
2
3
4
5
5
TB8
3
C14
W 98
C13
PILZ
V 97
A2
96
U
FUSE
R-
81
TB4
R+
82
98
W
V 97
U 96
81
R- EXTERNAL BRAKE
R+ 82
EXTERNAL BRAKE
98
W
97
V
U 96
R-
81 EXTERNAL BRAKE
R+ 82 EXTERNAL BRAKE
4
4
W
98
97 V
96
U
81 R-
EXTERNAL BRAKE
R+
82
EXTERNAL BRAKE
57
4
